Electronic Air Conditioning Leak Detector for Refrigerant Systems

Price: €109.50 214.16лв.

Code:

8557
Weight:

0.694 Kgs

Overview:
✔ Professional electronic leak detector for automotive and air conditioning systems
✔ Suitable for passenger vehicles, trucks and other refrigerant-based AC systems
✔ Compatible with R134a, R1234yf and multiple refrigerant types
✔ Adjustable sensitivity with LED indication for precise leak detection
✔ Optical and audible alarm when leaks are detected
✔ Automatic calibration and RESET function for improved detection accuracy
✔ Flexible 355 mm probe for hard-to-reach areas
✔ Continuous operating mode with fast response time

Electronic Air Conditioning Leak Detector for Refrigerant Systems

Send to friend

Rate this product

This electronic air conditioning leak detector is designed for fast and precise identification of refrigerant leaks in passenger vehicles, trucks and various air conditioning systems. The detector simplifies troubleshooting procedures and helps reduce diagnostic time during service and repair operations.

The device is suitable for the following refrigerants:

R134a
R1234yf
R12
R11
R500
R503
R22
R123
R124
R502
R404a
R125
AZ-50
HP62
MP39

Automatic Calibration and RESET Function

The detector features automatic calibration that recognizes the current refrigerant concentration surrounding the sensor immediately after startup and sets this level as a reference value.

Only concentrations above this detected level will trigger an alarm.

The RESET function provides similar functionality during operation:

Ignores refrigerant concentration currently measured at the sensor tip
Uses current concentration as a new reference point
Triggers alerts only when a higher concentration is detected
Can restore maximum sensitivity when reset in fresh air

After reset, all LED indicators turn off except the outer left LED, confirming the reset process.

Adjustable Sensitivity Control

The detector allows sensitivity adjustment during operation for improved leak localization and varying working environments.

Sensitivity adjustment:

▲ Sensitivity button: Increase sensitivity
▼ Sensitivity button: Decrease sensitivity
Current sensitivity level displayed by LED bar indicator

Higher sensitivity does not always provide better detection performance. If refrigerant already exists in the surrounding air, excessively high sensitivity can result in unnecessary alarm activation.

Optical and Audible Leak Detection Alerts

The unit provides both visual and audible indications when refrigerant leakage is detected.

Features:

Optical leak indication
Audible alarm indication
Extremely fast response time
Continuous operating mode without operating limitation

Flexible Probe Design

The detector is equipped with a flexible probe for improved accessibility in confined areas and difficult inspection points around air conditioning systems.

Probe specifications:
