Mobile Oil Drip Pan, 55 L
Price:
€525.00
-
Code:70153
-
Weight:20.000 Kgs
Overview:
✔ Collects engine, differential and transmission oil or antifreeze
✔ 55 L rated capacity; maximum pan volume 56.85 L
✔ Suitable for repairs close to the ground
✔ Removable mesh insert for placing oily components
✔ Rear-mounted hand-crank pump with 2250 mm hose
✔ Push handle, two fixed castors and two swivel castors
The rectangular pan collects oil or antifreeze during workshop repairs close to the ground. Its mesh insert can be removed when needed. The hand-crank suction pump at the rear is used to empty the pan through the hose.
Positioning in the workshop
A compact design and push handle help position the pan. It runs on two fixed castors and two swivel castors.
Technical specifications
- Rated capacity: 55 L
- Maximum pan volume: 56.85 L
- Length × width × height: 870 × 530 × 140 mm
- Ground clearance: 230 mm
- Fixed castor diameter: 120 mm
- Swivel castor diameter: 75 mm
- Mesh dimensions: 810 × 460 mm
- Hose length: 2250 mm
- Material: Sheet steel
